Model

QLG9404GYY

Usage

Load diesel,fuel

Tare weight

6800kg

Max payload

35000kg

Tank volume

43cbm

Tank material

5083 aluminum alloy

Overall dimension

11500mm*2500mm*3800mm

Main beam

T-structure 6061 aluminum alloy,down plate is 12mm,

middle plate is 10mm.

Tank compartments

13000L,17000L,13000L/3 compartments

Tank thickness

Tank body is 6 mm,front/end plate is 6mm, baffle is 6mm.

Manhole cover

Diameter 450mm-500mm/2pcs

Axle

BPW 13T/3pcs

Tire

315/80R22.5/12pcs

Rim

9.0-20/12pcs

Kingpin

Interchangeable 50#/90#

Landing gear

JOST C200

Suspension

German mechanical suspension

Leaf spring

100mm*11mm*12pcs/6sets

Discharge valve

DN100/1pc

Discharge pipe

8 meters each side tube/2pcs

Fire extinguisher number

2pcs

Spare tire carrier

1 standard

Water tank

30L

Tool box

1 standard

Braking system

With WABCO ABS system

Electrical system

24 voltage,7 wire harness.

Light

LED type

Painting

With shot blasting and 4 layers painting,color is optional.

Remark

The above mentioned data is for your reference only.

The detailed specification will be subject to our final confirmation.
